Mechanical Specifications

DMX connectors: 3-pin XLR connectors in & out

Display: Digital display(auto shut-off for display)

Power connection: Neutrix Power-Con in & out

Fastening System: 5 Threaded screw mounting points

Top: 2mm Arcrylic glass

Electrical Specifications

LED Quantity:288

Red: 96

Green: 96

Blue: 96

LED size:5mm,

Lamp power:0.2W

Led angle: 120 degree (± 5°)

16 LED strips inside

Power consumption:100-240v/50-60Hz

Ballast: Electronic

Control & Programming

Protocol: DMX512

3 DMX modes:

Mode1 5 DMX channels Dimmer/strobe, R, G, B,

and Macro (full panel)

Mode 2 12 DMX channels 4 X R, G, B

Mode 3 17 DMX Channels 4 X dimmer/strobe, R, G,

B and MacroS

Control options: Master & Slave, stand alone, sound-activation, Auto.

Fixture

Light Size: 50 x 50 x 8.2cm

Inner box: 55 x 55 x 15cm/6.2kg.

Thermal

Maximum ambient temperature: 40° C

Maximum surface temperature: 60° C
